Music Conservatory Lift
| Solution: | 127 |
|---|---|
| Industry | Entertainment Stage Lift Equipment |
| Model: | Music Conservatory Lift |
| Type: | Single Stage Lift |
| Actuation: | Hydraulic |
| Dimensions: | 190" × 120" |
| Travel: | 32" |
| Capacity: | 10,000 |
Overview
The University of Cincinnati's Music Conservatory contacted Handling Specialty to custom design and manufacture a hydraulic scissor lift to convey props/set pieces to the conservatory’s upper level, while also being used as a 10,000 lb capacity rollover access to the stage in the lowered position. When not in use, this pit-mounted lift remains in the fully raised position.
Features
- 10,000 lbs. capacity, hydraulic actuation, 119.5" x 189.75", 32" vertical travel
- Hydraulically actuated lock-up legs, double acting cylinders, safety touch bars at ends
- Adjustable mechanical down stops
- Quiet power unit
- PLC used for sequencing movements of the lift and lock-up legs
